| Type | (Cust.) Art. no. | PN | D1 | M | L2 | L3 | CAD | Legend | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Type | ELV-06LM 10x1,0 | Art. no. | 708.3654.180.20 | PN | 500.0 bar | D1 | 6.0 mm | M | 10x1.0 | L2 | 12.0 mm | L3 | 34.5 mm | CAD | Download | |
| Type | ELV-08LM 12x1,5 | Art. no. | 708.3654.190.20 | PN | 500.0 bar | D1 | 8.0 mm | M | 12x1.5 | L2 | 14.0 mm | L3 | 37.0 mm | CAD | Download | |
| Type | ELV-10LM 14x1,5 | Art. no. | 708.3654.260.20 | PN | 500.0 bar | D1 | 10.0 mm | M | 14x1.5 | L2 | 14.0 mm | L3 | 39.5 mm | CAD | Download | |
| Type | ELV-12LM 16x1,5 | Art. no. | 708.3654.340.20 | PN | 400.0 bar | D1 | 12.0 mm | M | 16x1.5 | L2 | 17.0 mm | L3 | 41.5 mm | CAD | Download | |
| Type | ELV-15LM 18x1,5 | Art. no. | 708.3654.532.20 | PN | 400.0 bar | D1 | 15.0 mm | M | 18x1.5 | L2 | 21.0 mm | L3 | 46.0 mm | CAD | Download | |
| Type | ELV-18LM 22x1,5 | Art. no. | 708.3654.574.20 | PN | 400.0 bar | D1 | 18.0 mm | M | 22x1.5 | L2 | 23.5 mm | L3 | 49.5 mm | CAD | Download | |
| Type | ELV-22LM 26x1,5 | Art. no. | 708.3654.635.20 | PN | 250.0 bar | D1 | 22.0 mm | M | 26x1.5 | L2 | 27.5 mm | L3 | 54.5 mm | CAD | Download | |
| Type | ELV-28LM 33x2,0 | Art. no. | 708.3654.850.20 | PN | 250.0 bar | D1 | 28.0 mm | M | 33x2.0 | L2 | 30.5 mm | L3 | 59.0 mm | CAD | Download | |
| Type | ELV-35LM 42x2,0 | Art. no. | 708.3654.944.20 | PN | 250.0 bar | D1 | 35.0 mm | M | 42x2.0 | L2 | 34.5 mm | L3 | 68.5 mm | CAD | Download | |
| Type | ELV-42LM 48x2,0 | Art. no. | 708.3654.992.20 | PN | 250.0 bar | D1 | 42.0 mm | M | 48x2.0 | L2 | 40.0 mm | L3 | 75.5 mm | CAD | Download | |
| Type | ELV-06SM 12x1,5 | Art. no. | 708.3654.195.30 | PN | 800.0 bar | D1 | 6.0 mm | M | 12x1.0 | L2 | 16.0 mm | L3 | 40.0 mm | CAD | Download | |
| Type | ELV-08SM 14x1,5 | Art. no. | 708.3654.245.30 | PN | 800.0 bar | D1 | 8.0 mm | M | 14x1.5 | L2 | 17.0 mm | L3 | 42.0 mm | CAD | Download | |
| Type | ELV-10SM 16x1,5 | Art. no. | 708.3654.270.30 | PN | 800.0 bar | D1 | 10.0 mm | M | 16x1.0 | L2 | 17.5 mm | L3 | 44.5 mm | CAD | Download | |
| Type | ELV-12SM 18x1,5 | Art. no. | 708.3654.350.30 | PN | 630.0 bar | D1 | 12.0 mm | M | 18x1.5 | L2 | 21.5 mm | L3 | 47.5 mm | CAD | Download | |
| Type | ELV-14SM 20x1,5 | Art. no. | 708.3654.504.30 | PN | 630.0 bar | D1 | 14.0 mm | M | 20x1.0 | L2 | 22.0 mm | L3 | 53.0 mm | CAD | Download | |
| Type | ELV-20SM 27x2,0 | Art. no. | 708.3654.506.30 | PN | 420.0 bar | D1 | 20.0 mm | M | 27x.2.0 | L2 | 26.5 mm | L3 | 64.5 mm | CAD | Download | |
| Type | ELV-16SM 22x1,5 | Art. no. | 708.3654.566.30 | PN | 420.0 bar | D1 | 16.0 mm | M | 22x1.5 | L2 | 24.5 mm | L3 | 54.5 mm | CAD | Download | |
| Type | ELV-25SM 33x2,0 | Art. no. | 708.3654.745.30 | PN | 420.0 bar | D1 | 25.0 mm | M | 33x2.0 | L2 | 30.0 mm | L3 | 72.5 mm | CAD | Download | |
| Type | ELV-30SM 42x2,0 | Art. no. | 708.3654.902.30 | PN | 320.0 bar | D1 | 30.0 mm | M | 42x2.0 | L2 | 35.5 mm | L3 | 78.5 mm | CAD | Download | |
| Type | ELV-38SM 48x2,0 | Art. no. | 708.3654.953.30 | PN | 320.0 bar | D1 | 38.0 mm | M | 48x2.0 | L2 | 41.0 mm | L3 | 89.0 mm | CAD | Download |
Adjustable male adaptor standpipe L fittings
with male adaptor connector, sealing edge form B acc. ISO 1179-4
SO Code:
-
Art. no.: -
Technical details
